Ametek Reichert XCEL 255 - Specifications; Physical and Electrical Specifications; Operational and Microscope Specifications

17
15120-101 Rev. D
Specications
Catalog Number 15120
Physical Dimensions
Size:Weight, unpacked: 23.0 lbs. (10.4 Kg)
Height: 19.8 in. (50.2 cm) Weight, packed: 52 lbs (23.64 Kg)
Width: 10.5 in. (26.7 cm)
Depth: 14.0 in. (35.6 cm)
Electrical
Voltage: 100-240 VAC
Power Input: Max 56-73VA
Frequency:50/60Hz
Fuses: T 1.6A L 250V
Halogen Bulb: P/N 15121 (6V, 20 W)
Operational Conditions
Environmental:
The environmental conditions are as follows:
Operating:
Temperature 10° C (50° F) to 35° C (95° F)
Relative Humidity: 30% to 75%
Atmospheric Pressure: 80 kPa (23.6 in. Hg) to
106 kPa (31.3 in. Hg)
Transportation & Storage:
Temperature -20° C (-4° F) to +70° C (158° F).
Relative Humidity: 10% to 80% (non-condensing)
Atmospheric Pressure: 50 kPa (14.8 in. Hg) to
106 kPa (31.3 in. Hg)
Exposure to extreme temperature conditions indicated above must not exceed 15 weeks.
Microscope Galilean
Mag Change 3 Step Drum Rotation
Eyepiece 12.5X
Mag Ratio 10X 16X 25X
PD Range 54 - 75 mm
Diopter Adjustment +/- 5
Slit Illumination 6V 20W Halogen
Slit Width 0 - 13.5 mm
Slit Length 0 - 13.5 mm
Slit Apertures 0.6, 5.8, 9, 13.5 mm
Slit Rotation 0° - 180°
Filters Red Free, Heat Absorbing, Cobalt Blue
-20°C
70°C
10%
80%
106 kPa
50 kPa
