Calibration and Troubleshooting
7-2 M370430-01 Rev F
Introduction
The calibration of the power supply is software dependent, and
there are no potentiometers to adjust.
Calibration is performed via SCPI commands. The following items
need to be calibrated:
Programmed voltage
Voltage readback
Programmed current
Current readback
Non-isolated voltage monitoring
Isolated voltage monitoring
Non-isolated current monitoring
Isolated current monitoring
Isolated source for analog programming
Non-isolated source for analog programming
Over voltage protection system
CAUTION: Equipment damage
Calibration procedures should only be performed by qualified user.
