Over-temperature
The output will be tripped off if a fault causes the internal temperature to rise
Line Regulation: Change in output for a 10% line change:
Constant voltage: <0.01% of maximum output
Constant current: <0.01% of maximum output
Load Regulation: Change in output for any load change within PowerFlex envelope, remote
sense connected:
Constant voltage: <0.01% of maximum output
Constant current: <0.05% of maximum output
Ripple & Noise
5mVrms max; typically <3mVrms, <15mV pk-pk, at maximum load, CV mode.
Transient Load
Response:
<250us to within 50mV of set level for a 5% to 95% load change.
Voltage Programming
Speed
(XPF60-20DP
only):
Maximum time required for output to settle within 1% of its total excursion
(for resistive load). Excludes command processing time.
Range and Setting 90% Load No Load 90% Load No Load
60V 7A
20V 20A
Up
Up
8ms
8ms
8ms
8ms
Down
Down
80ms
10ms
1.5s
1.2s
Status Indication: Output ON lamp.
Constant voltage mode lamp.
Constant current mode lamp.
Unregulated (power limit) lamp
Remote lamp
(XPF60-20DP only)
LAN lamp
Trip message on display.
METER SPECIFICATIONS
Dual 4 digit meters with 10mm (0.39") LEDs. Reading rate 4 Hz.
Meter Accuracies: Voltage 0.1% of reading ± 2 digits
Current 0.3% of reading ± 2 digits
ADDITIONAL SPECIFICATIONS
Independent Mode: Each output is fully independent and isolated. Operation is equivalent to two
VoltageTracking Mode:
(V
TRACK
)
With V
TRACK
selected the voltage controls of Output 1 (the Master) set an
identical voltage on Output 2. The outputs remain isolated and the current
controls remain independent.
Locking the Master (S-Lock) also locks the voltage of Output 2.
Slave voltage = Master voltage ± (0.1% of Master voltage ± 20mV)
Synchronous On/Off: In addition to the independent DC On/Off controls for each output, the outputs
can be turned on or off simultaneously using the Synchronous On/Off key.
This key operates in all modes.
