AMI 210BX - MODEL 210 BX Overview

ANALYZER OVERVIEW
Mounting Hole
(x 4)
LCD
Up and Down
Arrow Buttons
Exhaust Port
Span Gas Inlet Port
Sample Gas Inlet Port
3-way Selector Valve
(Sample/Span/Off)
Flow Meter
½" NPT Machined
Holes for Electrical
Connnections (x 2)
(not shown in image)
Explosion-proof
Enclosure
(left side view)
(front view)
Exhaust Port
Span Gas Inlet Port
Sample Gas Inlet Port
Cell Cap
Metering Valve
Protective Earth
Ground Lug
Mounting Plate
(right side view)
Warning/Caution
Information Plate
Case Earth
Ground Lug
(Note: No Customer Connections)
2
