AMI 210BX - Specifications

SPECIFICATIONS
PHYSICAL
Dimensions __________________________________________12.9”W x 10.0”H x 5.1”D (33 cm x 25 cm x 13 cm)
Weight _______________________________________________________________________ 16.0 lbs (7.26 kg)
Digital Display ______________________________________)4–digit LCD (reads full scale from 0.000% to 25.0%)
Mounting _______________________________________________________________ Wall mount or 2.0" pipe
Gas Connections ___________________________________________________ ¼" 316 S.S. compression fittings
Wetted Parts ___________________________________ 316 S.S. fittings, electro-less nickel-plated cell block, gold-
plated contacts, acrylic-flow meter & O-rings (Viton,
kalrez, and Buna-N)
Materials _________________________________________ Cases (painted aluminum, Door Seal (urethane foam),
Window (plastic), O-ring (neoprene)
Method of Measurement ____________________________________________________ Electrochemical Sensor
Key Technologies ____________________________Patented ELIMINATOR CELL BLOCK
TM
,
COMMAND CENTER Interface Software
(with Datalogger, Brown-out History, Power-up History, USB
Virtual Comport, Modbus RS485 and Modbus TCP/IP)
Proprietary Sensor Technology (for oxygen sensor)
Low Minimum Detection Threshold ________________________10 ppm –100 ppm, dependent on sensor selection
Response Time ________________________________________________________ 90% upscale response times:
P-2 P-3 P-4 P-5
8 sec 30 sec 30 sec 30 sec
Repeatability ____________________________________ ±1% of range or ±0.1% of oxygen, whichever is greater
Diurnal Temperature Specification __________________________________< 3% of scale over temperature range
Data Collection Capacity ______________________________15 days of data recording @1 datapoint per minute
Inlet Gas Pressure __________________________________________________ 0.5 –150 psig (0.03 –10.3 bar)
Protection _______________________________________________________________________ RFI-protected
Output Ranges__________________________ 4 user selectable ranges (0–1.0%, 0–5.0%, 0–10.0% and 25.0%)
optional ranges (
0 – 1000 ppm, 0 – 1.0%, 0 – 10.0%, 0 – 25.0%)
(
0 – 10.0%, 0 – 25.0%, 0 – 50.0%, and 0 – 100.0%)
Operating Temperature Range _______________________________ non-heated: 25°F to 115°F (-3.9°C to 46°C),
heated: -20°F to 115°F (-29°C to 46°C),
with Extreme Weather Enclosure: -40°F to 115°F (-40°C to 46°C)
Recommended Flow Rate _________________________________________________________ 0.1 to 2.0 SCFH
Isolated Analog Output Signals ______________________________________________ 1–5 VDC and 4–20 mA
TECHNOLOGY
PERFORMANCE
OPERATION
ALARMS
Number of Alarms _______________________ 2 Fully, Adjustable Oxygen Concentration Alarms with Dry Contacts
Alarm Delays _________________________________________________ Programmable from 0 – 300 minutes
Alarm Hold-off / Bypass _________________________________________ Programmable from 0 – 120 minutes
Alarm Relay Contact Rating __________________________________________________ 5A@115VAC or 24VDC
USAGE
Both indoor and outdoor use
Altitude for Use ______________________________ <2,500 meters for AC model and <5,500 meters for DC model
Relative Humidity___________________________________________________________ <95%, non-condensing
Ingress Protection__________________________________________________________________________IP65
