14 Amico Patient Care Corporation
Battery Replacement - Sentinel
Figure 7: Install Sensor Assembly - Step 6a
Figure 8: Install Sensor Assembly - Steps 6b & 6c
NOTE: Amico Patient Care Corporation highly recommends cleaning or replacing the Disposable
Body to avoid calibrating a contaminated Vacuum Regulator. Follow instructions on pages 8-9 of this
manual.
Battery Holder
Press Down on Sensor Assembly Gently Push Sensor Assembly
Forward
One Side is Slightly
Above the Guide
Insert Sensor Assembly
To Next Page
