3.6 Operation
•
Set the speed lever (1) in full load direction (MAX).
• Adjust the drive direction and speed at the drive lever (2).
• Guide and steer the machine at the tow bar; the operator
should go alongside the tow bar.
3. Operation
37
Attention
The motor has to cut-off by long working breaks;
long idle-runnings can take to great motor dam-
ages.
Important
For compaction of paving stones, it is recommended to
use Vulkollan plates and protective brackets (special
accessories) to prevent damages to the compaction
material and to the machine.
If the machine is used without protective bracket, the
threaded fastenings in the base plate must be sealed
with the supplied screw plugs .
Important
Under adverse conditions start-up of the exciter may
be impeded. Then the engine cannot reach its nominal
RPM. This can be remedied by activating the drive le
-
ver (2) several times.
