FIREFINDER SERIES II INSTALLATION, COMMISSIONING &
OPERATION
5.14.2 Mechanical
SmartTerminal can be supplied in three variants Slim Line ABS (externally powered) BX1 ABS
(externally powered) and BX1 ABS (internally powered) and consists of;
Note: A Communications Extender Board will be required if the Comms Bus in the FACP is fully
utilised and / or if one is not fitted.
The front door of the ABS version is locked by way of two clips on the right hand side of the cabinet.
A special locating key which has two raised pins that are inserted into the side of the cabinet unlocks
the door.
DOOR RELEASE PINS
DOOR RELEASE PINS
Figure 39: ABS Door Key and Front Panel Add On Card Surround Release Clip
CAB2116
2
