FIREFINDER SERIES II INSTALLATION, COMMISSIONING &
OPERATION
After scrolling through the groups and entering what I/O GROUPS will be turned
on by what module/s or device/s in a zone/s the operator is prompted to press
ENTER to confirm the entries and / or changes.
10.8.2 Device Programming
Press  DEVICE:
Use these keys to EDIT and move through wording & numbering
Use these keys to MOVE between fields i.e.: DESC & TYPE and next parameter
Enter the Loop and Sensor number then scroll through the following screens.
Press or Press
 To EDIT or  to DELETE
1. EDIT LxSx DESCRIPTION AND TYPE STRING. Edit then. Press
e.g.: DESC Loop 1 Sensor 1
TYPE SMOKE
2. Allocate / Edit the Sensor to a Zone and set the device type then. Press
e.g.: XP95 Photo, XP95 Heat etc-
3. Set /Edit and display the Output Configurations or options then. Press
e.g.: Latching, AVF, Non-latching etc
4. Set / Edits and enables / disables the day/night settings then. Press
5. Allocates / Edits the Loop and Sensors Groups.
After scrolling through the groups a prompt tells the operator to press ENTER to confirm the
changes.
10.8.3 Input Programming
Press INPUT:
By following the screen prompts as above Edit or Delete an INPUT in a panel or a loop.
Screen: PROGRAM MENU SELECTING AN INPUT
 IN A PANEL
 ON A LOOP
I/O MODULE
LOOP
Select I/O MODULE NO. then ENTER
Select LOOP NO. then ENTER
INPUT
SENSOR
Select I/P NO then ENTER
Select SENSOR NO. then ENTER
EDIT / DELETE DESC
INPUT
Select INPUT NO. then ENTER key
ALPHA KEYS ARE ACTIVE
EDIT Lx Sx I/Px DESC STRING DESC
