LOOPSENSE EN54 USER MANUAL
Sub-Address Suffix:
 - Sub-Address Disabled
6.1.6 Add-On Point Selection
Add-On module addresses 1 up to 30 can be selected, depending on type.
SELECT ADD-ON: XX <add-on type>
<selected add-on descriptor>
►A1 A2 A3 A4 A5
A6 A7 A8 A9 A10
Add-On Address Prefixes:
 A – Add-On configured
 X – Add-On not configured
Add-On Address Suffix:
* - Add-On Disabled
6.1.7 Panel Input Point Selection
Panel digital inputs 1 to 4 can be selected.
SELECT INPUT: X <input type>
<input descriptor>
►I/P1 I/P2 I/P3 I/P4
Panel Input Prefix:
 I/P – Panel Input
Panel Input Suffix:
 - Panel Input Disabled
6.1.8 Panel Output Point Selection
4 panel Supervised Outputs, 3 Relay Outputs, 2 Open Collector Outputs and 2 Auxiliary Outputs can
be selected.
SELECT OUTPUT: X <output type>
<output descriptor>
►O/P1 O/P2 O/P3 O/P4
Panel Output Prefix:
 O/P – Panel Output
Panel Output Suffix:
 - Panel Output Disabled
6.1.9 Password User ID Selection
User IDs 1 and 2 can be selected at the panel.
SELECT USER ID: X
►ID1 ID2
