LOOPSENSE EN54
USER MANUAL
Press NEXT► to go to the next field.
Press NEXT► to go to the next field.
EDIT CONTACT STATE: NORMALLY OPEN
Press NEXT► to go to the next field.
Press NEXT► to go to the next field.
EDIT PRE-DELAY: 0 (0-90 seconds)
Press NEXT► to go to the next field.
The user shall then be prompted to save any changes if they have been made.
7.6.3.2 Menu->Programming->Panel->Output
1►SUPERVISED O/P 3|OPEN COLLECTOR O/P
2|RELAY O/P 4|AUXILIARY O/P
The user may select between the four types of panel outputs.
SELECT OUTPUT: X <output type>
<output descriptor>
►O/P1 O/P2 O/P3 O/P4
There are 4 Supervised Outputs, 3 Relay Outputs, 2 Open Collector Outputs and 2 Auxiliary Outputs
to choose from.
Depending on the output type selected, the number of available outputs shall be displayed on the
generic output point selection this screen
<output descriptor>_
#CLEAR DEL ▲
Press enter to edit the selected output configuration settings.
