Event ID
String
Description
17
Thermal Memory Loss
The system was unable to read the Thermal Memory
value from Battery Backed up Ram while booting.
The Motor Overload value will be initialised to 100%.
18
Main Contactor Opened
The main contactor auxiliary contact opened while in
run mode.
19
RTX Parameter Error
There was an error with the RTX parameter dongle.
20
Shunt Earth Continuity
Trip
The resistance of the pilot to earth was less than the
trip level.
21
Thermal Memory Reset
The thermal memory was overridden by user
intervention & reset to zero.
22
RTX Stop
The RTX stop input was activated causing an outlet
stop.
23
RTX Offline
The RTX went offline causing an outlet trip.
24
Insulation Trip
The pre-start high voltage insulation test failed.
25
RTX Comms Timeout
RTX is online, but there was repeated data
corruption.
26
Power Up
The system has powered up after a clean power
down.
27
Under Voltage Trip
The phase voltage dropped below the trip level
causing the outlet to drop out of run mode.
28
Stopped
General log denoting when the system completed
the request to drop out of run mode.
29
No Coil Voltage Trip
Logs when a ‘No Coil Supply’ trip occurred.
30
CT Detection Error
The earth leakage system could not detect an
adequate toroid connection.
31
Remote Start Stuck
The remote start button was detected to be closed
for longer that the trip limit.
32
PLC Comms Timeout
The PLC failed to provide ‘heart beat’.
33
Start Disabled
The Protection Element was disabled by the PLC
34
Earth Fault Lockout
Trip
The resistance measured between the phases and
earth during an intrinsically safe EFLO test was
below the set level.
35
Unknown Restart
Status
The system has powered up, but cannot work out if
the system powered down cleanly or if it had a
restart.
36
Short Circuit Trip Reset
A short circuit trip was reset.
