Amphenol SLPPC70BSB1 - Step 5: Install Grommet and Cable Gland and Back Shell

Step 5: Install grommet and cable gland and back shell
步骤
5
：组装橡胶密封圈和密封压盖和后壳
Tighten back shell to the indicated location shown as picture above by hand or tool.
通过手或工具拧紧外壳至上图所示的位置.
The recommended torque as below:
推荐扭矩如下：
50mm²: 2.5~3.0N.m
70mm²: 3.5~4.0N.m
85mm²: 3.5~4.0N.m
