DETAILED SPECIFICATIONS
Ambient temperature: 23°C ±5°C (73.4°F ±9°F); Relative temperature: ≤75%
Accuracy: ±(% of reading + digits)
Maximum voltage between input terminal and earth ground:
1000V ac True-rms or 1000V dc.
Fuse for mA µA input: F1 0.5A H 1000V fast-fuse, (Φ6.3×32)mm
Fuse for 10A input: F2 11A H 1000V fast-fuse, (Φ10×38)mm
Maximum display: Digital 5999 counts, updates 3/seconds.
Analog pointer display: 61 segments. Updates 20 times/seconds.
Over-range indication: OL
Range: Automatic and Manual
Altitude: Operating ≤ 2000m
Operating temperature: 0°C~+40°C (32°F~104°F)
Relative humidity: 0°C~+30°C (32°F~86°F) ≤75%; +30°C~+40°C (86°F~104°F) ≤50%
Storage temperature: -10°C~+50°C (14°F~122°F)
Electromagnetic compatibility: In an RF filed of 1V/m = Specified accuracy ± 5%
Battery: 9V, 6F22, NEDA1604 or equivalent
Low battery indication:
Dimensions (L x W x H): 182 mm x 90 mm x 45 mm (7.2 in x 3.5 in x 1.8 in)
Weight: Approximately 354g (0.78 lb) with batteries installed
1. DC Voltage Measurement
Range Resolution Best Accuracy
600.0mV 0.1mV ±(0.5%+3 LSD)
6.000V 1mV
±(0.5%+2 LSD)60.00V 10mV
600.0V 100mV
1000V 1V ±(1.0%+2 LSD)
Input impedance: Around 10MΩ ;
Overload protection: ±1000V
