Screen Display
1
Auto- or Manual- range
2
Direct current
3
Negative reading
4
Alternate current
5
True-rms value
6
Low battery indicator
7
Data hold
8
Diode test
9
Continuity test
10
Relative zero mode
11
Non-contact Voltage
detection mode
12
Measurement units
for Resistance
13
Measurement units
for Frequency
14
Measurement units for Voltage
15
Measurement units for Current
6
9
5
2 4
3
7
10 19 2011 21
26
16
17
13
12
14 15
18
28
27
25
24
81
2223
16
Measurement units for Capacitance
17
Duty cycle
18
Auto power off
19
Maximum / minimum reading
memory
20
Positive / negative peak
reading memory
21
Measurement unit for temperature
22
Low-pass filter
23
400KΩ low-impedance test
(AM-570 / AM-550-EUR only)
24
Temperature measurement T1 or T2
25
Temperature measurement T1 - T2
26
Warning for error input terminals
connection for test leads
27
Hazardous Voltage presence
28
Analog bar graph display
