AM-560 Advanced HVAC Multimeter
AM-570 Industrial Multimeter
AM-540-EUR / AM-550-EUR Digital Multimeter
1
Flash light
2
LCD Display
3
Push buttons (See making measurement for button functions)
4
AM-570 / AM-550-EUR: Low-impedance button
AM-560 / AM-540-EUR: Backlight button
5
Rotary switch
6
SELECT button
7
Input terminal for voltage, diode, capacitance, resistance,
continuity and temperature measurement
8
COM (return) terminal for all measurements
9
Input terminal for AC/DC mA/uA measurement
10
Input terminal for AC/DC A measurement to10A
6
7
1
2
3
4 46
5
7
89
10
