1.3 AMSTRAD MP1 Modulator/Power supply and a domestic
(UHF) Colour TV receiver.
The MP1 is an additional item that you may wish to purchase if you are currently using your
CPC464 computer with the GT64 green tube monitor. The MP1 enables you to use the computer
with your domestic colour TV and thereby enjoy the full colour facilities of your CPC464 computer.
Unpack the Modulator/Power Supply (MP1) and connect a Mains Plug to the Mains Lead of the MP1
as follows:
WARNING
Disconnect the Mains Plug from the Supply Socket when not in use.
No internal connections need to be made, therefore no attempt should be
made to gain access to the inside of the equipment.
Figure 2: The MP1 modulator and power supply
IMPORTANT
The wires in this Mains Lead are coloured in accordance with the following code:
Blue: Neutral
Brown: Live
If a 13 Amp (BS1363) Plug is used, a 5 Amp Fuse must be fitted. The 13 Amp Fuse
supplied in a new Plug must NOT
be used. If any other Plug is used, a 5 Amp Fuse
must be fitted -
either in the Plug, or Adaptor or at the Distribution Board. As the
colours of the wires in the Mains Lead of this apparatus may not correspond with the
coloured markings identifying the terminals in your Plug, proceed as follows:
The wire which is coloured BLUE must be connected to the terminal which is marked
with the letter ‘N’ or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal which is marked
with the letter ‘L’ or coloured RED.
