AMSTRAD CPC464 - AMSTRAD CTM640 Colour Monitor

1.2 AMSTRAD CTM640 Colour Monitor
Unpack the monitor and connect a Mains Power Plug to the Mains Lead as follows:
WARNING
Disconnect the Mains Plug from the Supply Socket when not in use.
No internal connections need to be made, therefore no attempt should be made to gain access to the
inside of the equipment.
The computer should be positioned in front of the Monitor on a suitable table close to the Mains
Supply Socket. As shown in figure 1,on the previous page, connect the lead with the larger (6 pin
DIN) Plug from the monitor to the socket marked MONITOR on the back of the computer. Connect
the lead with the smaller (DC power) Plug from the monitor to the socket marked 5V DC on the back
of the computer.
Ensure that the monitor POWER button is set to the OFF position. Connect the Mains Plug from the
monitor into the Mains Supply (240v AC) socket.
Now switch on the monitor, and then switch on the computer using the slide switch marked POWER
on the right hand end.
IMPORTANT
The wires in this Mains Lead are coloured in accordance with the following code:
Blue: Neutral
Brown: Live
If a 13 Amp (BS1363) Plug is used, a 5 Amp Fuse must be fitted. The 13 Amp Fuse
supplied on a new Plug must NOT
be used. If any other Plug is used, a 5 Amp Fuse
must be fitted -
either in the Plug, or Adaptor or at the Distribution Board. As the
colours of the wires in the Mains Lead of this apparatus may not correspond with the
coloured markings identifying the terminals in your Plug, proceed as follows:
The wire which is coloured BLUE must be connected to the terminal which is marked
with the letter ‘N’ or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal which is marked
with the letter ‘L’ or coloured RED.
