MXA-MP/MPL Modero X Series® Multi Preview and Multi-Preview Live
Features
Supports one HD digital video stream or up to 10 preview images.
Updates all 10 preview images sequentially or one image continuously.
Streams digital video sources to a Modero X Series Touch Panel.
Multi-format video input accepts HDMI and DVI.
Seamlessly interconnects between a Modero X Series Touch Panel and an Enova DGX or Enova
DVX.
Product Specifications
The MXA-MPL supports the delivery of HDMI 1.4a (w/HDCP) content to a Modero X
Series touch panel. The MXA-MPL has a HDMI input and delivers that video content
to the Modero X Series panel over a dedicated link using a proprietary interface.
MXA-MPL (FG5968-10) Specifications
Power Requirements: MXA-MPL only: 120VAC at 170ma (20W)
MXA-MPL with touch panel: 120VAC at 410ma (50W)
Start-Up Inrush Current: 17.2A at 116.8VAC
Video:
Max Number of Active Video
Streams:
1
Video Preview Image Format: JPEG (accessed over HTTP)
Max Number of Video Preview
Images:
10
Min Refresh Time of Preview
Images:
2 sec per preview image
Video Input: HDMI, DVI, RGBHV, S-Video, composite or component video
Video Input Resolutions: Video Input Resolutions supported:
• HDMI/DVI: 640 x 480p @ 60 Hz, 800 x 600p @ 60 Hz, 1024 x 768p @
60 Hz,1280 x 720p @ 60 Hz
• PAL: 576i, 576p@50 Hz
• NTSC: 480i, 480p@60 Hz
Video Input Resolutions not supported:
• 1280 x 768p @ 60 Hz, 1920 x 1080p @ 60 Hz
Video Input Resolutions
Supported By Firmware Release
Greater Than 2.1.28:
• HDMI/DVI: 1024 x 768p @ 60 Hz, 720 x 480i @ 60 Hz, 720 x 480p @ 60
Hz
• PAL: 576i, 576p @ 50 Hz
• NTSC: 480i, 480p @ 60 Hz
Video Output: Up to 720p @ 30 fps over IP (Matches input resolution)
Communications: 10/100 port, RJ-45 connector with Ethernet/IP pass-through
Audio Input: Unbalanced 1/8th-inch mini-jack connector (for use with non-HDMI audio
only)
Front Components:
Power LED: Lights green when device is receiving power.
Status LED: Toggles on/off green every 5 seconds if communicating to the panel.(i.e.:
the panel is configured to use the MXA-MPL).
Video Input LED: Lights red when receiving video signals.
LAN LED: Lights green when the LAN connection is enabled.
Panel LED: Lights green when device is connected to a panel.
Video Output LED: Lights red when sending a video stream to a touch panel.
Reset button: Reboots the device when pressed.
