AMX Multi Preview User Manual

Installation
12
MXA-MP/MPL Modero X Series® Multi Preview and Multi-Preview Live
To install an MXA-MP or MXA-MPL in a MPA-VRK Rack Mounting Tray:
1. Select a position on the Rack Mounting Tray for the installation. The Rack Mounting Tray contains screw
holes to allow single or double device installations (FIG. 7).
2. Using the installation screws included with the MPA-VRK, install the screws to the bottom of the device
through the Rack Mounting Tray (FIG. 8). Use four screws for each device, with one at each corner.
3. Connect the Rack Mounting Tray to the rack with the provided installation screws.
4. Connect the device to the network and apply power.
FIG. 8 Installing two MXA-MP devices in a Rack Mounting Tray
Screws
MXA-MP MXA-MPL
MPA-VRK
