AMX MXT-701 User Manual

Modero X Series® G5 Touch Panels
7
MXD/T-701 7" Modero X Series® G5 Touch Panels
MXD-701 Specifications (Cont.)
Touch Panel Display (Cont.):
Screen Resolution
(W x H):
• Landscape: 1024x600
• Portrait: 600x1024
Aspect Ratio
(W x H):
• Landscape: 16:9
• Portrait: 9:16
Brightness: 400 cd/m2
Contrast Ratio: 700:1
Color Depth: 16,7M colors
Backlight Type: LED
Touch Overlay: Projected Capacitive; Multi-touch support, 3 simultaneous max.
Communications:
Ethernet: 10/100 port, RJ-45 connector and cable. Supported IP and IP-based protocols:
UDP, TCP, ICMP, ICSP, IGMP, DHCP, SSH, DNS, RFB (for VNC), HTTP
USB: 1 - USB host 2.0, Type A ports
Near Field Communications
(NFC):
Supports standards ISO/IEC 15693, ISO/IEC 14443A, ISO/IEC 14443B; Unique Identifier
(UID), Typical Range = .25", Maximum Range = .5"
Video:
Supported Video Codecs: • MPEG2-TS: MPEG-2 Main Profile @High Level up to 720p at 25 fps, H.264 (decode
only)
• MJPEG up to 720p at 25 fps (decode only)
Streaming/File Formats: MPEG-TS for H.264, MPEG2; HTTP for MJPEG
Audio:
Streaming/File Formats: WAV, MP3
Intercom: Full Duplex VoIP
* (see note)
Operating
Environment:
• Operating Temperature: 32° F to 104° F (0° C to 40° C)
• Storage Temperature: 4° F to 140° F (-20° C to 60° C)
• Humidity Operating: 20% to 85% RH
• Humidity Storage: 5% to 85% RH
• Power ("Heat") Dissipation: On: 27.3 BTU/hr, Standby: 10.9 BTU/hr
Dimensions (HWD):
• Landscape: 4.8" x 7.3" x 2.5" (122 mm x 186 mm x 63 mm)
• Portrait: 7.3" x 4.8" x 2.5" (186 mm x 122 mm x 63 mm)
Weight:
1.4 lbs (0.64 Kg)
Certifications: • FCC Part 15 Class B
• C-Tick CISPR 22 Class B
• CE EN 55022 Class B and EN 55024
• CB Scheme IEC 60950-1
•IC
• IEC/EN-60950
• RoHS/WEEE compliant
Included Accessories: • MXD-701 Installation Guide (93-5968-54)
• MXA-CLK Modero X Series Cleaning Kit (FG5968-16)
• MXD-701 Installation Template (68-5968-04)
• MXD-701 Back Box (68-5968-04)
Other AMX Equipment: • PS-POE-AF-TC, POE Injector, 802.3af Compliant (FG423-83)
• CB-MXP7, Rough-In Box and Cover Plate for Modero X Series Touch Panel, 7"
(FG039-18)
• NXA-ENET8-2POE, Gigabit Switch, 8 Port POE, 2 Port SFP (FG2178-63)
• MXA-RMK-07, Rack Mount Kit (FG5969-63)
• MXA-FMK-07, Flush Mount Kit (FG5968-71)

AMX MXT-701 Specifications

General

Screen shape	Flat
Display diagonal	7 \
Touchscreen type	Tabletop
Display brightness	400 cd/m²
Display resolution	1024 x 600 pixels
Native aspect ratio	16:9
Touchscreen technology	Capacitive
Product color	Aluminium, Black
Built-in processor	Quad Core
HDMI ports quantity	0
Graphics card	G5 Graphics
NVIDIA G-SYNC	No
