4.2 Unpacking and inspecon

• 1 x 

• 1 x Power supply cord

• 1 x Ethernet cross cable (for device update)

• 1 x Remote Control Soware (RCS²)*

• 1 x Set of 6 audio 5-pin screw terminals

• 1 x Front rack ears (the parts are stowed in the packaging foam)

• 1 x User manual (PDF)*

• 1 x Quick start guide*

* User manual, quick start guide and the RCS² are available on www.analogway.com

Before racking and plugging any inputs and outputs, it is advised to power on the unit. Should you encounter

any issue, you must contact immediately your local distributor or dealer, or closest  technical

support oces (see chapter: 12. Contact informaon).

 The QuickMatriX can be used directly on a table; the unit is equipped with 4 handy an-

slip rubber feet.

 The QuickMatriX is compable with a 19” enclosure. Please follow the instrucons below to

install the device in a 19” rack.

Place the device in your rack. Aach the device to the rack by screwing 2 front ears on it (screws not included).

Rear xing is also recommended, in parcular for permanent installaons.

Connect all of the cables of the device and aach them to the rack with the help of e wraps.

IMPORTANT:

- The openings in the side of the device are for cooling. Do not cover these openings to avoid blocking air

circulaon.

- Be sure that no weight in excess of 2 kg (4.4 Lbs.) is added onto the QuickMatriX.

- The maximum ambient operang temperature should not exceed 40°C (104°F).

- The rack and all mounted equipment in it must be reliably grounded according to naonal and/or local

electrical standards.

4.2 

4.3 

Dismantling front handles of the device could invalidate warranty on aer-sales services of your

QuickMatriX. It is strongly advised to avoid using front handles as rests for your QuickMatriX,

they are designed for manipulaon purposes only.

If required, front handles of the device can be dismantled, but with cauon. The original screws removed

must not be reintroduced to their locaon without handles in place. Substanal damages can occur,

including risk of electric shock from the main voltage. Only M4x12mm screws can be used. They are

supplied with the unit.
