4.4 Cable and adaptator informaon
A large choice of cables and adaptors are compable with the QuickMatriX. Please refer to the hardware
specicaons chapter to nd the most suitable cables for your operaons.
For each type of signal, here are the levels and the impedance accepted by the QuickMatriX.
4.4
4.5
Type Levels
Composite 0,7 Vpp + 0,3 Vpp 75 Ω
S. Video Y = 0,7 Vpp + 0,3 Vpp
C = 0,7 Vpp
75 Ω
YUV Y = 0,7 Vpp + 0,3 Vpp
U = 0,7 Vpp
V = 0,7 Vpp
75 Ω
RGsB R = 0,7 Vpp
G = 0,7 Vpp + 0,3 Vpp
B = 0,7 Vpp
75 Ω
RGBS
R, G, B = 0,7 Vpp R, G, B = 75 Ω
S = 0,3 Vpp 75 Ω
or
S = TTL
Type Levels
YUV Y = 0,7 Vpp + 0,3 Vpp
U = 0,7 Vpp
V = 0,7 Vpp
75 Ω
RGsB R = 0,7 Vpp
G = 0,7 Vpp + 0,3 Vpp
B = 0,7 Vpp
75 Ω
RGBS
R, G, B = 0,7 Vpp R, G, B = 75 Ω
S = 0,3 Vpp 75 Ω
or
S = TTL
Type
SD-SDI YUV - 10 bits – 4.2.2 - 270 Mb/s
No payload ID management
Only A-level type
DVI RGB ou YUV – 8 bits – 4.4.4 – 16/235 - TMDS
HDMI RGB or YUV – 8 bits – 4.4.4 or 4.2.2
– 16/235 – TMDS
HDBaseT RGB or YUV – 8 bits – 4.4.4 or 4.2.2
– 16/235
Type Levels
YUV Y = 0,7 Vpp ±0,3 Vpp
U = 0,7 Vpp ±0,3 Vpp
V = 0,7 Vpp ±0,3 Vpp
75 Ω
RGsB R = 0,7 Vpp ±0,3 Vpp
G = 0,7 Vpp ±0,3 Vpp
B = 0,7 Vpp ±0,3 Vpp
75 Ω
Type
HD-SDI YUV - 10 bits – 4.2.2 – 1,485Gb/s and
1,485/1.001Gb/s
Only A-level type
Input and output payload ID management
for HDTV format only
3G-SDI YUV - 10 bits – 4.2.2 – 2,97Gb/s and
2,97/1.001Gb/s
Only A-level type
Input and output payload ID management
for HDTV format only
DVI RGB or YUV – 8 bits – 4.4.4 – 16/235 - TMDS
HDMI RGB or YUV – 8 bits – 4.4.4 or 4.2.2
– 16/235 – TMDS
HDBaseT RGB or YUV – 8 bits – 4.4.4 or 4.2.2
– 16/235
Type
DVI RGB or YUV – 8 bits – 4.4.4 – 16/235 - TMDS
HDMI RGB or YUV – 8 bits – 4.4.4 or 4.2.2
– 16/235 – TMDS
HDBaseT RGB or YUV – 8 bits – 4.4.4 or 4.2.2
– 16/235
Digital SDTV
Digital HDTV
Digital EDTV
These formats are compable with bi-level and tri-
level sync on 1 or 3 wires.
