8.2.9 Capturing frames
STRETCH UP
HARD
STRETCH RIGHT HARD
STRETCH LEFT HARD
STRETCH CURTAIN
IN HARD
STRETCH CENTER
OUT HARD
STRETCH CENTER
IN HARD

It is possible to store up to 8 frames in the QuickMatriX non volale memory. To capture a frame, display the
exact content you want to save on one of your outputs, at the exact resoluon, you can use the freeze buon
if you want. Then follow this step:

Choose the frame number slot and wait unl the unit nishes to save. Your frame is now saved and you can
use it through the Quick Frame buon.
The capture of frames can be done only under the following condions:
- The capture can be done from the Program output #1 or the Program output #2,
- The disappearance of frames on the Program output is normal during saving.
A frame captures the state of the specied output at the output resoluon, and must be recalled using the
same output resoluon. Resizing or other image manipulaon of the captured frame is not possible.
Aempng to use a frame at a dierent resoluon will result in a paral frame display or a frame which does
not ll the screen. During the capture, the output is outlined by a white border and includes the pixels into
the white rectangle.

Frames are mainly used as quick frames in a typical show or event setup, and can be recorded from any of the
QuickMatriX 8 sources and called back at the press of a single buon. To use a frame, be sure rst that it is
well saved, then aect the frame to the Quick Frame layer going into the SCREEN menu then QUICK FRAME.
To acvate the Quick Frame, simply press the front panel Quick Frame buon.

In the frame input setup menu, you have the possibility to save a frame, and the possibility to erase a stored
frame:



The QuickMatriX allows the creaon of user dened presets very easily. Any setup you have congured on
screen, can be stored into one of the 8 available user presets.
1. Aer having congured layers, transions, ... on your screen, go to the Preset menu by pressing the 
MENU buon, and select Preset by rotang the scroll knob. Then, press the ENTER buon to enter the
Preset sub-menu. Choose Preset Copy by scrolling with the corresponding knob, and press the ENTER
buon to access the sub-menu.
2. In the sub-menu, choose both screens or only Screen 1 or Screen 2 to determine which screen you want to
memorize the preset from, then set the preset memory (#1 to #8) you wish to use as your “User Preset
(by default, the QuickMatriX will choose the next available preset in the QuickMatriX memory).
By pressing the ENTER buon, the QuickMatriX will ask you to conrm. Select Yes, your screen is memorized
as a preset.
