53
 set up the type of color space of your DVI output,
 DVI output content as HDMI. Audio is included,
 set up the type of color space of your HDMI output,
 HDMI output content as DVI,
enable or not the HDCP detecon on the output,
 display the centering test paern,
 choose to display one of the available test paern.
All changes have to be validated by pressing the ENTER buon in order to be saved
NOTE: The output status can provide you all informaon about the output in real me. This feature is
parcularly needed when HDCP is used with long cable to be sure that the communicaon is well
handled.

To work with Matrix mode, you rst have to select the source then the output where you want to put the
source.


Press TAKE to view the result on both screens

Once a source is assigned to a layer, you will have access to some layer sengs in the Layer menu or direct-
ly by pressing the layer buon.
The sengs available depend on the layer selected:
 set up layer size and posion,
set up layer zoom size and posion,
 adjust a specic size (Fullscreen, 1/2, 1/3, ...),
 adjust the layer transparency,
 choose the border and adjust its properes,
 adjust the Open/Close eect type and duraon,
 enable/disable smooth move,
 get the selected layer status.
All changes have to be validated by pressing the ENTER buon in order to be saved
8.2.5 Working with layerss
1 layer 
The QuickMatriX has the possibility to use a second layer. This layer can be displayed only with a
controler (RCS², RK-350 or Verge™). This layer has to be keyed. If not, it will be displayed in black.
