4.6 Input specicaons
The QuickMatriX uses an HDMI plug with a standard
mounng screw above the connector. Please see the
diagram below.
This hole is occupied by a Torx10 screw when you receive
the unit. If desired, this screw can be removed and
replaced by a compable aermarket HDMI plug locking
mechanism to ensure a secure HDMI connecon. This
threaded hole should not be le empty.
This hole is used by a TX10 screw when you receive the unit, if you wish to use an HDMI cable with a security
xing screw you can take this screw o and use your own in order to insure good xing of your HDMI plug.
Please take a look at the accepted formats regarding the input plug type:
WARNING: Only the video and audio signal is processed for the HDMI®, and 3G/HD/SD-SDI inputs; other
embedded auxiliary features are not supported or passed through. The embedded audio is processed. All
other HDMI® features such as: HDMI Ethernet Channel, Audio Return Channel, 3D, 4K, Content Type, Deep
Color and x.v.Color are NOT supported.
Plug Type  Signals
Universal Analog Input SDTV - EDTV - HDTV - Computer Analog SDTV - Analog EDTV - Analog HDTV - Analog Computer
DVI-D Input SDTV - EDTV - HDTV - Computer Digital SDTV - Digital EDTV - Digital HDTV - Digital Computer
HDMI Input SDTV - EDTV - HDTV - Computer Digital SDTV - Digital EDTV - Digital HDTV - Digital Computer
HDBaseT Input SDTV - EDTV - HDTV - Computer Digital SDTV - Digital EDTV - Digital HDTV - Digital Computer
3G/HD/SD-SDI Input SDTV - HDTV Digital SDTV - Digital HDTV
M3x0,5 mm
27 mm
The (only for Ref. QMX150-H) is equipped with two HDBaseT input connectors.
In addion of the management of the embedded audio streams, the HDBaseT inputs also support the Ether-
net pass-through and the Power Over Ethernet (PoE+ with 48V and 30W) funconalies.
The following table indicates the LED status of HDBaseT inputs plugs:
Status  
LED o No Link No HDMI Video
Low Blink Ethernet Fallback Mode Not Applicable
Medium Blink Low Power Mode without Ethernet HDMI content without HDCP encrypon
Fast Blink Low Power Mode with Ethernet Not Applicable
LED on HDBaseT Link HDMI content with HDCP encrypon
