Ananda D16 User Manual

- 5 -
◆
Mileage data (ODO, single trip, single trip time, max speed, average speed, average power,
Instantaneous power consumption, motor power, riding power, remaining distance and riding
frequency)
◆
PAS level
◆
6km/h walk assist
◆
Turn on/off headlight, brightness control automatically (According to the light intensity of the
external environment)
◆
USB charging function, output voltage/max output current: 5V/1A
◆
Wireless function (Optional)
◆
Setting functions: Single trip distance Clearance, Backlight Setting, Speed unit, Power Unit;
Factory reset, wireless status and name(Optional), Automatic shutdown time and customized
data showing setting function.
◆
Read only information:
Motor firmware version number, motor hardware version number, motor serial number,
wheel diameter, odometer;
Battery firmware version number, battery hardware version number, battery serial number,
battery voltage, battery cycle times, battery SOH;
Display firmware version number, display hardware version number and display serial number;
◆
Automatic control of backlight brightness (According to the light intensity of the external
environment)
◆
Error code
◆
Multi set up parameters
Standard parameters of D16 Display:
◆
According to EN 15194:2017 Standard
◆
Wireless function meets the requirements of RED certification (Only for the display with
wireless function)
◆
Display Supports ADST function (For details, please refer to "ADST programming tool full
function (Standard Version) operation manual")
◆
Communication protocol: “Ananda new European standard display controller v11.0 protocol_
Version 1.3.4” and above, (The latest version from Ananda shall prevail and be compatible
with previous versions)
◆
Match with wide voltage battery including 24V/36V/48V
◆
The maximum working current is 50mA
2.2 Normal Display Figures
