- 7 -
3. Note for users
Be care of the safety use. Don’t attempt to release the connector when battery is on
power.
Try to avoid hitting.
Don’t split the waterproof sticker to avoid affecting the waterproof performance
Don’t modify system parameters to avoid parameters disorder.
Make the display repaired when error code appears.
4. Installation Instruction
Fix the display onto the handlebar and adjust to an appropriate visual angle.
Power off the
E-bike, plug the connector of the display with the connector corresponding to the controller to
complete the installation.
5. Normal Operation
5.1 On/Off
◆
When the battery has output current, the display turned on. If long press the battery Switch button,
the battery will be turned off, and the display will automatically shut down at the same time, and
the system will be shut down.
◆
When the battery has output current, the display turned on. If the display is turned off first and
then the battery is turned off, and the system is turned off.
◆
When the battery has output current, if the display has been turned on, press and hold the display
switch button for 2 seconds, and the display will be closed. If the display is not turned on, press and
hold the display switch button for 1 second to turn on the display.
◆
If the system is not used for several minutes (the specific time can be set in the instrument
parameter setting / automatic shutdown time setting item), the display will sleep automatically,
and the display dormant current is less than 6 mA.
◆
If the system has not been used for 30 minutes, the battery and the whole system will turn off
automatically
◆
After the display is powered on, the "ANANDA" start-up interface is displayed first, and then
the main interface is entered. In the main interface, the display can enter the locking interface
through wireless control. When shutting down, the "ANANDA" shutdown interface will be
