USER MANUAL DENTAL UNIT - QS4-451-01 / SD 300 Scandinavian
7
7.- TRANSPORT AND DIMENSIONS
The dental unit is suitably packaged and protected. (Fig. 2)
The package includes the dental unit secured to a pallet, with a further two cases containing the
water unit and colibri forceps system.
It is essential that none of the boxes are knocked when in transit, and under no circumstances
must they fall to the floor. Great care should be taken when moving the equipment; we
recommend transportation by Antoni Carles, S.A. authorized technicians.
Before assembling the unit, a technician, along with yourself and the authorized member of staff
on-site should determine its best location with regard to comfort and ergonomics.
Should you have to move a pre-assembled unit, fit the chair first with the seat
at its lowest position and the back raised, and make sure the water unit and
instrument tray are fully retracted over the chair at all times, keeping the unit as
solid as possible.
Once in its new position, remember to secure the chair to the floor
Water cabinet must also be fixed to floor or secured over stabilizing platform.
0,1
0$;
0,10$;
Fig. 2
