USER MANUAL DENTAL UNIT - QS4-451-01 / SD 300 Scandinavian
11
8.3.- Instrument-tray
The instrument tray (Fig. 6), ergonomically designed to facilitate the work of the user, has a
capacity for 5 instruments.
Optional instruments (4 in total) can be set to interchangeable work positions (except for
ultrasounds and the MX micro-motor which do not allow a swap). Main features:
- It has a touch control interface panel: Touch Expert. Consult the user manual for further
details about its features and how to access the different information menus for the various
configuration and adjustment functions
- The Touch Expert panel provides access to the auxiliary instruments and controls, manual
movements and seat memory, automatic position saving function, as well as how to
configure other characteristics (identifying the centre, doctor, working language, statistics
about the use of the equipment).
- The touch screen provides access to instrument configuration functions, making it possible
to personalise the values for each user, with a capacity for up to four doctors, such as electric
micro-motor maximum turning speed, light intensity, counter-angle value, ultrasound
working modes (depending on the model) and regulation of ultrasound intensity. Two types
of programming have been defined: technical and user mode. The value of these variables
is displayed on screen.
- The configuration screens provide access to the timer functions for the water unit: glass
and cup of water.
- The auxiliary functions can also be activated via the Touch Expert control: switching on the
operating and auxiliary lamp.
- Automatic detection and graphic display of errors
- Display showing instrument water flow, measured through regulators installed beneath the
instrument tray.
- Interchangeable electric micromotor with 3 work positions.
- Pantographic arm with pneumatic brake for comfortable, effortless front positioning (handle
side).
- Silicon instrument support protects instruments against knocks. Can be sterilised and
easily removed for autoclave sterilisation.
- Auxiliary instrument tray installation.
- Thanks to the smooth, rounded, non-porous shape of the instrument tray, it it easily
accessible for cleaning and disinfecting.
- Arm levelling (authorised technician only)
- Arm brake adjustment (authorised technician only)
- Overhead poles protect the instrument if droppedfrom falls.
- Lamp effect in optional light-fitted instruments activated without using the pedal (except
ultrasound).
Should the turbine or micromotor spray function not work, or if there is no water
in the ultrasound, check that these regulators are fully opened by turning them
anticlockwise.
Safety:
To block any button-activated memory, press the control pedal.
When activating the control pedal, all chair movements are blocked.
This pedal does not allow any automatic memory to be saved nor does it accept
it, so preventing unexpected movements, except for return-to-zero.
