USER MANUAL DENTAL UNIT - QS4-451-01 / SD 300 Scandinavian
24
APPENDIX 2. METASYS AMALGAM SEPARATOR
Before removing the water unit cover or extracting the vessel, disconnect the
dental unit from the mains by turning off the general power switch.
Use suitable protective gloves.
As shown in figure 14, remove the outer cover of the water unit (A), by first pulling it lightly
towards you then lifting. Note that it is held at the top using 2 magnets (B) and below using the
supports (C). You will find the tank installed (D).
Before carrying out any maintenance, cleaning or disinfecting procedures, to check the working
order of the unit or should you have any doubts, please refer to the original manufacturer
instructions included in the documentation delivered with the dental unit. Always use cleaning
and disinfecting products recommended by the manufacturer.
D
Fig. 16
