Bundguard 5 12.01.2022 Rev.4
11
3. Installation
3.1 Control Panel Mounting
The control panel houses all electrical and electronic circuitry and connection points and must be
mounted externally to the bund, located such that the panel will not be submerged in normal operation.
The control panel is typically mounted on the bund wall or mounting frame attached to the bund wall,
using either the M6 wall anchors or M6 bolts provided within the fixing kit. There are 4 x 20mm
mounting holes in the base of the control panel for entry of the mains power, telemetry, pump power
and sensor cables. The fixing kit provides CW20S gland for SWA mains power and telemetry cables and
M20 plastic glands for the pump and sensor cables.
3.2 Sensor and Pump Mounting
The pump(s) and sensor unit are placed at the lowest point of the bund. Most bunds have a section that
has a floor lower than that of the majority of the bund floor; this is called a ‘sump’. If a sump is present,
that is where the BundGuard pump and sensor unit should be located.
The pump and sensor unit are included with 10m long cables to connect to the control panel. Consult
the connection diagrams in this section prior to applying power to the BundGuard control panel.
The anti-syphon device is supplied in the fixing kit should be positioned at the highest point, where the
discharge hose passes over the bund wall for example. The arrows moulded into the body of the anti-
syphon device should point in the direction of the outflow (away from the pump).
! The anti-syphon device must not be located inside the bund.
