3.3 Panel & Sensor Connections
The BundGuard is supplied in one of two connectivity configurations. Option 1 as detailed below:
! Installation should only be carried out by suitable trained personnel.
Option 1 Terminal Configuration
Term.
N
o
Name
Description
Incoming Power connection
1
Input Neutral
RCD Mains Neutral
2
Input Live
RCD Mains Live
3
Input Earth
Mains Earth
Pump Power connection
4
Pump 1 Neutral
Un-switched neutral for pump 1
5
Pump 1 Live
Switched live for pump 1
6
Pump 1 Earth
Un-switch earth for pump 1
7
Pump 2 Neutral
Un-switched neutral for pump 2
8
Pump 2 Live
Switched live for pump 2
9
Pump 2 Earth
Un-switch earth for pump 2
Common Alarm 230Vac Output Connections
10
Common Neutral
Un-switched neutral for beacon or sounder
11
Common LIVE
Switched live for beacon or sounder
12
Common Earth
Un-switched earth for beacon or sounder
Telemetry (relay) connections
13
Pump2 Disable Relay
Pump 2 disable NO relay contact
14
Pump1 Disable Relay
Pump 1 disable NO relay contact
15
Mains Fail Relay
Mains failure NC relay contact
16
High Oil Relay
High oil NO relay contact
17
System Fault Relay
System fault NO relay contact
18
High Water Relay
High water NO relay contact
19
Relay Common
Common connection to all alarm relays
Sensor Connection
20
Oil +VE
Positive switch connection to oil float switch
21
Oil -VE
Negative switch connection to oil float switch
22
High Water Probe (red)
High water probe from sensor unit
23
Start Probe (Yellow)
Start probe from sensor unit
24
Stop Probe (blue)
Stop probe from sensor unit
25
Common probe (Black)
Common probe from sensor unit
Auxiliary Equipment connections ( Filter /flow meters)
26
GND
Control panel signal ground
27
+12V
Control panel signal +12V
28
Pressure 1 input
Pressure 1 sensor 4-20mA or switched input
29
Pressure 2 input
Pressure 2 sensor 4-20mA or switched input
30
Flow input
Flow rate sensor 4-20mA input
