4.1.10.12 Response
If the request was correct, the response will be formatted as shown below:
Field
Name
Total bytes
Data type
1
Address ID
1
Unsigned integer
2
Function code (0d67/0x41)
1
Unsigned integer
3
Event number
1
Unsigned integer
4
Event.time
4
Unsigned 32bit integer
5
Event.ID
1
Enumeration
6
CRC
2
Checksum
Fields 4 and 5 provide the data for the requested event. Field 4 is a 32-bit unsigned integer. This value is
a unix time-stamp (POSIX time) of when the event occurred.
[A unix time stamp is a count of the number of seconds since 1970-01-01]
Field 5 provides an enumeration of the event that occurred. The enumeration table is shown:
Event
enum
Description
Text
0
The sensor unit probes entered an unknown error state
ER 0 Probe Error
1
The sensor unit detected a high water state
High water
2
The sensor unit detected a high oil state
High oil
3
The sensor unit detected a high water short state
ER 1 HIGH SHORT
4
The sensor unit detected a start water short state
ER 2 START SHORT
5
The sensor unit detected a stop water open state
ER 3 STOP OPEN
6
The sensor unit detected a start water open state
ER 4 START OPEN
7
Pump 1 was measured drawing a current above the threshold
Pump1 > limit
8
Pump 2 was measured drawing a current above the threshold
Pump2 > limit
9
The plug and play connector was disconnected
Connector N/C
10
Pump 1 disable circuit was engaged
Pump1 disable
11
Pump 2 disable circuit was engaged
Pump2 disable
12
Filter pressure 1 was measured above the threshold
Pressure1 > lim
13
Filter pressure 2 was measured above the threshold
Pressure2 > lim
14
The BundGuard engaged battery power
Batt engaged
15
Pump 1 was disabled due to repeated over-current alarms
Pump1 >Cur Disab
16
Pump 2 was disabled due to repeated over-current alarms
Pump2 >Cur Disab
17
The GSM module has connected to a network
GSM connecting
18
The BundGuard disengaged battery power
Batt disengaged
19
The BundGuard lost mains (and battery, if installed) power
Unit powered OFF
20
The BundGuard was powered up by mains or battery power
Unit powered ON
21
The on-board processor was reset (processor resets itself automatically on
power up)
Processor reset
