Andel Bundguard 5 - System Setup

Bundguard 5 12.01.2022 Rev.4
13
4. System Setup
After physical installation, the systems settings may require adjusting this is achieved through the
installer interface, the table below give details of the menu structure of the interface and further details
of the operation and settings of each menu items follow.
Menu system
Menu Items
Description
Menu 0/8 – Date and time
Sets date and time
Menu 1/8 – Pump & alarms
Menu for setting pump and alarms
Num. Of Pumps
Sets number of pumps 1 or 2
Set threshold
Set pump current threshold 0-5000mA
Autochange Over
Sets auto changeover (on / off)
HWA Delay
High water alarm delay 0 -60 minutes
View Current
View pump current (mA)
Overcurrent trip
Sets overcurrent protection on or off
Pump delay
Sets pump on delay 3-30 seconds
Main fail
Set mains fail alarm on or off
Menu 2/8 - Modbus
En/Disable
Enable / Disable Modbus communications
RS485
No user options available
Modbus I/D
Set Modbus address 01 - 247
Modbus baud rate
Set Modbus baud rate 300-57600
Listen only
Sets listen mode on or off
Menu 3/8 - Filter
Pressure measure
Filter type
Set type of filter (switched, measurement)
Set thresh 1
Set threshold for filter 1
Set thresh 2
Set threshold for filter 2
Set Num. Of filters
Set number of filters 1 or 2
Pressure @20mA
Set Pressure at 20mA
Pressure @4mA
Set pressure at 4mA
View Pressure
View current pressure reading
Menu 4/8 – Flow meter
Meter Enable
Set meter to on or off
Current flow
View current flow reading
Flow @ 20mA
Set flow at 20mA
Set flow at 4mA
Set flow at 4mA
Menu 5/8 -connector
Set connector disconnect on or off
Menu 6/8 - GSM
En/disable GSM
Enable disable GSM
Set forwarding Number
Set number to send message to
View details
View GSM detail (see page xx)
SIM status
Status of SIM card
Network Status
Network status
Operator name
Name of mobile operator
Menu 6/7 - History
View event history 1 to144(max) events
Menu 8/8 - Info
Serial Number
Panel serial number
Debug code
Debug code (for fault finding)
