SPECIFICATIONS
Ø 3/4" FNPT DRAIN
17-5/8
1-11/16
4-7/16
32-11/16
35
37
25
UP TO 1/2" DIAMETER ROD
24
90-2433
FIGURE 1 – DIMENSIONS (INCHES)
ELECTRICAL A320V1 A320V3
Voltage 208-240 VAC (~), 1ø, 60 HZ 277 VAC (~), 1ø, 60 HZ
Operating Current 11�1A @ 80°F, 60% RH 9�1A @ 80°F, 60% RH
Efficiency
2�9 L/kW-hr (6�0 pints/kW-hr)
@ 80°F, 60% RH
2�6 L/kW-hr (5�5 pints/kW-hr)
@ 80°F, 60% RH
ENVIRONMENTAL
Operating Temperature Range 50°F – 104°F
Operating Dew Point Lower Limit 40°F
MECHANICAL
Weight 180 lbs (without packaging)
Drain Size 3/4" FNPT
Capacity 320 PPD @ 80°F, 60% RH
Filter MERV 11
Airflow 830 CFM (free flow)
DIMENSIONS
English 3
