Circuit breaker safety switch information codes
The circuit breakers printed circuit board (PCB) is fitted with 3 LED (diodes) green, yellow and
red color see photo on the previous page.
The LED’s gives information function about the actual drift, they have the following function:
Green: normal operation. The LED lights constant for 5minutes, and flashes
afterwards
Yellow: a error has occurred, the number of flash tells the error type
Red: a serious error has occurred, count the yellow flash for error type
Green LED
The green color LED alone indicates that there is power on, when circuit breaker is “ON” and
everything is ok. The green LED lights constant light from start (power up), and starts flash for
every 20 seconds after 5 minutes.
Yellow LED
Yellow LED flash indicates errors. Every error type has a number and by counting the flash when
an error occur the error number can be detected. The error type will be flashed for every 20sec.
count the flash and see the table for error type.
The yellow LED is the normal error count LED that tells what error tripped the circuit breaker.
General is the higher error number equal to more serious errors
Red LED
If the red LED flash, when yellow is off, a very serious fault is present, count the yellow flash.
Either it’s because that:
the circuit breaker can not be tripped by the PCB,
the yellow wires from the motor thermo switch has an interrupt,
the electric connection to the PCB main +motor and +battery is wrong.
Errors codes count the numbers of flashes on the circuit breaker yellow LED:
3 Battery voltage higher than limit at power up, check battery charger
4 High current consumption at power up, check for failure
5 Extremely low voltage, check battery charger and electric installation
6 Low voltage, check battery charger and electric installation
7 Low continuously current consumption (15min or more), check electric installation
8 High continuously current consumption (8 min or more), check electric installation
9 High voltage, during motor running, check battery charger
10 High voltage, check battery charger
11 Extremely high voltage, check battery charger and electric installation
13 Thermo switch in motor activated, or could also be damaged wiring
14 Wrong PCB connection, switch over +motor and +battery cable on breaker
