14
Manufactured by: Ronstan Denmark ApS. - Jægervænget 36 - 7100 Vejle – Denmark - info@andersenwinches - www.andersenwinches.com
Important electric installation information
Incorrect system polarity will permanently damage the motor
To protect your Compact motor, make sure that the power is
supplied through the circuit breaker unit (delivered with your
compact motor)
Notice that the circuit breaker shall be placed near the battery –
see wiring diagram.
Make sure that the thermal cut out protection in the motor (yellow wires) is connected via
extension cables to the circuit breaker printed circuit board
Observe that the wiring dimensions given on the wiring diagram are met.
You can use shorter and / or thicker wires than indicated – but never longer and thinner
No other devices than the provided circuit breaker (and possible main fuse
>160 A, and / or main switch) must be installed between the compact motor terminals and the
battery terminals
No other devices than the Compact motor must be connected to the circuit breaker.
Never supply the motor from an external power supply but exclusively from the battery. For
12V motors the supply voltage must be within 10,5V-15,5V. For 24V motors the supply voltage
must be within 21V-28,5V
If the battery is charged from the grid, disconnect the circuit breaker or main switch to avoid
electronic damage on the motor caused by high voltage spikes
Check that the (unloaded) voltage of any generator(s) does not exceed 15,5V for 12V systems -
and 28,5V for 24 V systems. Be sure that the alternator does not charge with higher voltage than
15,5 (12V system) or 28,5 volt (24volt system)
Never alter control cable wiring
Always disconnect the power when not in use to avoid accidental activation.
See wiring diagram on the next pages.
Any deviation from the above listed instructions will
invalidate the warranty!
