Andersen 28 User Manual

18
Manufactured by: Ronstan Denmark ApS. - Jægervænget 36 - 7100 Vejle – Denmark - info@andersenwinches - www.andersenwinches.com
Below deck Motors 28-72ST
(Ø195 & Ø250)
1. With the unit removed from the boat unscrew the 6 or 8 bolts from the bottom of the motor.
2. Separate the motor unit from the gear unit by lifting the gear unit up. If difficult to separate, tap
the gear house with a plastic hammer while pulling apart.
3. Clean the top of the motor including the gear, re-lubricate the gear with Andersen Winch Grease
Andersen Winch Grease and place it to one side.
4. With the shaft pointing up, remove the 6 bolts connecting the flange to the gear housing, and
remove the flange and the shaft.
5. Remove the pawls and springs.
6. Clean all parts and check for excessive wear.
7. Reassemble the shaft assembly applying a thin coat of Andersen winch grease and mount new
pawls and springs – place to one side.
8. Clean the shaft base and the surrounding ball bearings on the gear housing. Do not remove the
bearings.
9. Re-lubricate the bearings and shaft base
10. Reattach the shaft and flange onto the gear housing.
11. With the flange attached turn the motor so the flange is pointing down.
12. Supporting the motor, clean and Re-lubricate the gears with Andersen Winch Grease.
13. Reattach the motor to gear unit. (Use the bolts to help align the motor to the gears)
