20
Manufactured by: Ronstan Denmark ApS. - Jægervænget 36 - 7100 Vejle – Denmark - info@andersenwinches - www.andersenwinches.com
Above deck Motors 46/52/58/62ST
(Ø195 & Ø250)
1. With the unit removed from the boat
take off the stainless steel cover and
unscrew the 2 bolts from the top of the
unit.
2. Remove the motor unit from the gear
unit. If difficult to separate, tap the gear
house with a plastic hammer while
pulling apart.
3. Clean the top of the motor including the
gear, re-lubricate the gear with Andersen
winch grease and place it to one side.
4. Place the gear housing upside down on 2
blocks so that the gear on the top of the
housing is not touching the work
surface.
5. Remove the 6 bolts retaining the crown
gear.
6. Carefully remove the crown gear, clean
it and place it to one side.
7. Clean the planet gears and the bearings,
taking care not to dislodge the bearings.
8. Lubricate the gears and bearings and
reassemble the crown gear.
9. Re-connect the motor unit to the gear
unit. Replace the gasket if damaged. Use
the bolts to align the motor to the gear
unit.
Above Deck 68/72ST
(Ø280)
1. With the unit removed from the boat,
mark up how the motor is placed in the
gear house
2. Remove the motor unit from the gear
housing, by removing the 8 bolts. If
difficult to separate, tap the gear house
with a plastic hammer while pulling
apart.
3. Clean the top of the motor including the
gear, re-lubricate the gear with Andersen
winch grease and place it to one side.
4. Place the gear housing upside down on
2 blocks so that the gear on the top of
the housing is not touching the work
surface.
5. Remove the 8 bolts retaining the crown
gear.
6. Carefully remove the crown gear, clean
it and place it to one side. Do not
remove the bearings.
7. Re-lubricate the bearings base in the
crown gear and the gears, and
reassembly again.
8. Re-connect the motor unit to the gear
unit. Replace the gasket if damaged. Use
the bolts to align the motor to the gear
unit.
