GAS CONVERSION
NOTE: Conversion and gas adjustment must be carried out by authorised
personnel only.
All ranges are supplied for use with Natural Gas unless specially ordered for
use with Propane Gas. To convert the appliance to Propane Gas will require
switching injectors, removal of the Natural Gas Regulator, fitting of test point
assembly and adjustment of the low flame setting.
INLET PRESSURE (kPa)
Minimum
Natural gas 1.0 kPa
LP gas 2.75 kPa
GAS BURNER INJECTOR CONVERSION
To switch injectors, unscrew fixed injector using a proper 7 Hex. key tool and
replace it with new injector for new gas setting.
For proper injector size, follow Burner’s Technical Data chart and fig. 7.
LOW SETTING VALVE ADJUSTMENT
The LOW setting should produce a stable flame when turning the knob from
HIGH to LOW. The flame should be 5mm or lower and must be stable on all
ports on LOW setting.
To adjust: Operate burner on HIGH for about five minutes to preheat burner
itself. Turn knob back to LOW; remove knob, and insert a
small flat tip screwdriver into the centre of the valve stem.
Adjust the flame size by turning adjustment screw in either
direction, while holding the stem (fig. 17)
Flame must be of sufficient size to be stable on all burner ports.
If flame adjustment is needed, adjust ONLY on the LOW setting.
Never adjust flame size on higher setting.
Fig. 17
