INSTRUCTION GUIDE FOR OVEN
OVEN CONTROL FEATURES
CONTROL MENU:
MODEL AXC1200FWT - The left hand 70cm oven is composed of an
electronic programmer, selector switch and a thermostat and the right hand
45cm oven is composed of a manual timer, selector switch and thermostat.
ON AND OFF NEON INDICATOR
When the Neon indicator is on the oven is
electrically powered and functioning, see fig. 4.
Fig.4
TEMPERATURE NEON INDICATOR
Temperature neon indicator turns on and off to
indicate the elements are turning on and off to
maintain the desired oven temperature, see fig. 5.
ELECTRONIC PROGRAMMER
The clock has a maximum setting of Time of day 11h 59 Min. or 23h 59 Min.,
Cooking end time 11h 59 Min. or 23h 59 Min., Minute minder 23h 59 Min.,
and Cooking duration 10h.
Functions:
Cooking duration, Cooking end time, Time of day, Minute minder “-“ , “+” ,
Manual selection.
Displays:
4-digit 7-segment display for time of day and switching times.
“Dialogue” display to identify condition of timer:
Duration and Manual mode = Cookpot symbol
Automatic programme = A
Minute minder = Bell symbol
o
C
fig.5
