Andrew ATC200-Lite Teletilt - Section 6 Changing the Electrical Downtilt on a Single Antenna

Bulletin 639510 May 2005 6-1
Section 6
Changing the Electrical Downtilt on a Single
Antenna
The electrical downtilt may be adjusted on any device that is addressed, congured, and
whose current state does not prevent antenna movement. Examples where movement is
prevented include devices that are not responding to commands from the program, devices
that are in the middle of a move or conguration change, and devices that are experiencing
a mechanical malfunction.
1. From the ‘Device Information’ list, click on the device to be moved (Figure 6-1).
2. Click ‘Move Selected’ at the bottom of the screen (Figure 6-1).
Figure 6-1. Selecting Device for Electrical Downtilt Adjustment.
1. Click on individual device to select for tilt move.
2. Click ‘Move Selected’.
