andrews MAXXflo - Page 21

MAXXo Water Heater
2121
INSTALLATION • SECTION 3
CWH30 & CWH60 FLUE SYSTEMS
e CWH30 & CWH60 uses a concentric ue system, 125mm outside diameter with an inner ue of 80mm diameter.
Flue components t together with silicon sealing rings and the ues are retained with sealing clamps. Each heater can be
ordered with either a horizontal or vertical ue kit. Flue assembly instructions are also included.
Standard Length Cut
A2
Hori zontal Kit
Minimum
Service
Clearance
Add standard
or cutable
flue to improv e
access to tank
top for inspection
(see page 35)
Vertica l Kit
Minimum
Service Clearance
Sealing Clamp
it roof
be cut
A1
to su
Can
Wall
300
t sWall P a el
Wall
to suit wall thickness
Sealing Clamps
A1
300
Service Clear
Minimum
ance
Hori zontal Kit
A l ternativ e Fl ue Systems
o suit wall thickness
tandard Length Cut
A2
t
S
52 8
Wall Plates
C pslam
A1
e lS a ni g
Wall
010
With this application
pipes must clear
Horizontal Flue
B260 – Horizontal ue kits include the following:
A1 – 90° bend with sealing clamp (Part No. E071)
A2 – Wall outlet terminal with sealing clamp
complete with inner and outer wall plates
xing screws and plugs. (Part No. E073)
B261 – Vertical ue kits include the following:
A1 – Roof outlet terminal with sealing clamp. (Part No. E067)
Roof ashing plates and additional Flue components are
available.
Optional ue components available
Part No Description
E071 90° elbow c/w clamp
E308 45° elbow c/w clamp
E064 1m length of ue c/w clamp
E070 1m length cutable ue c/w
clamp
E069 0.5m ue c/w clamp
E065 Flat roof plate (125mm)
E066 Angled roof plate (125mm)
E068 Wall clamp (125mm)
E105 Guard for horizontal ue
terminal
E310 Flue condense trap
B260 Horizontal ue terminal
B261 Vertical ue terminal
E211 Condensate trap bottle
E075 Flue clamp 125mm
E261 Condense trap pipe kit
Add standard
or cutable ue
to improve
access
to tank top for
inspection (See
page 36
