CWH90 & CWH120 FLUE SYSTEMS
e CWH90 & CWH120 uses a concentric ue system, 200mm outside diameter with an inner ue of 130mm
diameter.
Flue components t together with silicon sealing rings and the ues are retained with sealing clamps.
Each heater can be ordered with either a horizontal or vertical ue kit. Flue assembly instructions are also included.
Standard Length Cut
A2
Hori zontal Kit
Minimum
Service
Clearance
Add standard
or cutable
flue to improv e
access to tank
top for inspection
(see page 35)
Vertica l Kit
Minimum
Service Clearance
Sealing Clamp
it roof
be cut
A1
to su
Can
Wall
300
t sWall P a el
Wall
to suit wall thickness
Sealing Clamps
A1
300
Service Clear
Minimum
ance
Hori zontal Kit
A l ternativ e Fl ue Systems
o suit wall thickness
tandard Length Cut
A2
t
S
52 8
Wall Plates
C pslam
A1
e lS a ni g
Wall
010
With this application
pipes must clear
Horizontal Flue
B262 – Horizontal ue kits include the following:
A1 – 90° bend with sealing clamp (Part No. E215)
A2 – Wall outlet terminal with sealing clamp
complete with inner and outer wall plates
xing screws and plugs. (Part No. E240)
B263 – Vertical ue kits include the following:
A1 – Roof outlet terminal with sealing clamp. (Part No.
E670)
Roof ashing plates and additional Flue
components are available.
Optional ue components available
Part No Description
E215 90° elbow c/w clamp
E216AWH 45° elbow c/w clamp
E212 1m length of ue c/w clamp
E213 1m length cutable ue c/w
clamp
E214 0.5m ue c/w clamp
E217 Flat roof plate (200mm)
E218 Angled roof plate (200mm)
E219 Wall clamp (200mm)
E630 Guard for horizontal ue
terminal
E220 Flue condense trap
B263 Vertical ue terminal
B262 Horizontal ue terminall
E211 Condensate trap bottle
E385 Flue clamp 200mm
E261 Condense trap pipe kit
Add standard
or cutable ue
to improve
access
to tank top
for inspection
(See page 36
SECTION 3 • INSTALLATION
