English
To assemble appliances in banks (side by side)
proceed as described below.
1 - Pull off the knob (A).
2 - Undo the screws (B) and remove the control
panels (C).
3 - Apply masking tape to the edges to be placed
side by side.
4 - Apply food-approved sealant to the edges to be
placed side by side.
5 - Place the appliances side by side.
6 - Connect the appliance using the screws and
nuts (D-E).
7 - Remove the excess sealant and the masking
tape.
8 - Apply the sealant to the inside of the lid (F), and
fit it to cover the fixing zone.
9 - Replace the control panels (C) and the knobs
(A) on completion of the operation.
A variety of optional installation kits are available for
arranging appliances in banks:
G)"Over cupboard" installation kit
H)"Bridge" installation kit
ASSEMBLY APPLIANCES IN BANKS
F
A
B
C
D
E
G H
