EN 67 2015/02 Rev. 1.0
OptiFresh Bean
3.2.2 Positioning
1 Place the machine at work top on a firm, flat surface.
2 If available, place the machine on a base cabinet.
3 Make sure that the area on the left of the machine is at least
11 cm to open the door.
4 Make sure that the area above the machine is at least 22 cm
to remove and/or refill the canisters.
5 Turn the feet (A) at the back of the machine to level the
machine.
3.2.3 Water connection
1 Connect the machine (A) to a tap (B) with air valve.
2 Open the tap and check for leakage.
3 If necessary, connect the machine (A) with the hose (B) to
the filter system (C) and connect the filter system with the
hose (D) to a tap.
A
B A
A
D
C
B
