LED Output Current --- The menu allows to set desired current output to each LED zone depending up
used LEDs
Zone 1 – 350mA per channel for 1Watt LEDs (Cree MC-E RGBW multichips) or
700mA per channel for Luxeon K2( ProLight Opto 3Watt Proeon)LEDs
:
Zone 8– 350mA per channel for 1Watt LEDs (Cree MC-E RGBW multichips) or
700mA per channel for Luxeon K2( ProLight Opto 3Watt Proeon)LEDs
Warning: Set the LED Output Power before connecting the LED modules to the driver. Never connect
1Watt LEDs to the 700mA output otherwise these LEDs vill be destroyed.
LEDs Power Limiting --- The menu item alows to reduce total current for desired zone. If option "O󰀨" is
selected, max. total current is allowed but for option "On" total current (sum of each channel currents) will be
reduced to 1200 mA max.
Important: If the ArcPower 384 Rack Mount is used for control of the ArcPad 48, two rules has to be kept:
1. The LEDs power limiting has to be set On at zone for which is the ArcPad 48 connected.
2. The LEDs output current has to be set on 700mA at zone for which is the ArcPad 48 connected.
Maximum Fade Time --- Select this menu item to set a desired max. fade time (0.1-25.5 sec.). This adjusted
fade time inuences fade of Red, Green, Blue ,White and dimmer at each zone during DMX operation:
If time between two receiving DMX values is > than fade time set in the item “M Ftime“, the entire adjusted
fade time will be used.
If time between two receiving DMX values is < than fade time set in the item“M Ftime“, the adjusted fade time
will be reduced to ll entire time between the two receiving DMX values.
e.g “Maximum Fade Time“=2sec. and xture has received Red=0 DMX, after 5 seconds will receive Red=255
DMX. It means, that red will go to full intensity during 2 seconds (and 3 seconds will stay in full intensity).
“Maximum Fade Time“=8 sec. and xture has received Red=0 DMX, after 5 seconds will receive Red=255 DMX.
It means, that red will go to full intensity during 5 seconds. (Max, fade time is reduced from 8 sec. to 5 sec.).
The Maximum Fade Time inuences R,G,B,W, colour macro and Dimmer at each zone and also the global
dimmer.
Default Settings --- The menu item sets all xture parameters to the default (factory) values.
10.4 Test sequences
Use this menu to run test program or user programs 1-3 without an external controller.
10.5 Manual mode
Preset E󰀨ects --- Select this menu to call up preset channel e󰀨ects.
Manual E󰀨ect control --- Use this menu for full control of each channel e󰀨ect.
Note: if DMX mode 6 is selected, items Zone 1-8 colour macro and itms Dimmer 1-8 are not displayed.
10.6 Stand-alone setting
Use this menu to set options used in stand-alone mode, as a selection of the running program, programming
and modifying programs.
Presetting Playback --- This function allows you to select the program which will be played after switching the
xture on. Selected program will be played in a loop.
Disabled –the option disables the “Presetting playback” function.
Test Program - The option will start built–in demo sequences.
Program 1 - the option will start a program No.1.
Program 2 - the option will start a program No. 2.
Program 3 - the option will start a program No. 3.
Note. If any program from this menu is has been selected and the xture is switched o󰀨 and on (and receives
a DMX signal), the xture does not reply to DMX and will run this program.
Playing program --- Use this menu to run a desired program in a loop.
Test Program In Loop - the option starts built–in demo program.
Program 1 In Loop - the option starts program No. 1.
Program 2 In Loop - the option starts program No. 2.
Program 3 In Loop - the option starts program No. 3.
