8. ArcPower 384 Rack Mount - Control menu map
Default settings=Bold print
Menu Level 1 Menu Level 2 Menu Level 3 Menu Level 4 Menu Level 5 Menu Level 6
Fixture Address DMX Address 001-512
Dynet Zone 1-255
Ethernet Settings Set Ethernet Mode Disable Ethernet
Ethernet
Set IP Address Default IP Address
Custom IP Address
Set ArtNet Universe 0-255
Fixture Information Power On Time Total Hours
Resetable Hours
Air Filters Set Alert Period 10...50...300 hours
Elapsed time
Fixture temperature Current Board 1 Temp.
Board 2 Temp.
Max. Nonresetable Board 1 Temp.
Board 2 Temp.
Maximum Resettable
Board 1 Temp.
Board 2 Temp.
DMX Values Red LEDs 1 0-255
:
Dimmer 0-255
Software Version IC1 MB1
IC2 MB1
IC1 MB2
IC1 DS
IC2 DS
Product IDs Mac Adr.
RDM UID
Personality User Mode User A Settings
User B Settings
User C Settings
DMX Preset Mode 1 Ch.1 Red LEDs 1
:
Ch. 24 Blue LEDs 8
Set Active
Mode 2 Ch.1 Red LEDs 1
:
Ch.32White LEDs 8
Set Active
Mode 3
Ch.1 Red LEDs 1
:
Ch.35 Dimmer
Set Active
Mode 4 Ch.1 Red LEDs 1
:
Ch. 4 Dimmer
Set Active
Mode 5 Ch.1 Red LEDs 1
