1-4 681XXC OM
681XXC
Model
Frequency Output Power
Output Power
w/Step Attenuator
Output Power
w/Electronic
Step Attenuator
68117C 0.01 – 8.4 GHz +13.0 dBm +11.0 dBm +9.0 dBm
68137C 2.0 – 20.0 GHz +13.0 dBm +11.0 dBm +3.0 dBm
68147C 0.01 – 20.0 GHz +13.0 dBm +11.0 dBm +3.0 dBm
68167C
0.01 – 2.0 GHz
2.0 – 20.0 GHz
20.0 – 40.0 GHz
+13.0 dBm
+9.0 dBm
+6.0 dBm
+11.0 dBm
+7.0 dBm
+3.0 dBm
Not Available
68177C
0.01 – 2.0 GHz
2.0 – 20.0 GHz
20.0 – 40.0 GHz
40.0 – 50.0 GHz
+11.0 dBm
+10.0 dBm
+2.5 dBm
+2.5 dBm
+10.0 dBm
+8.5 dBm
0.0 dBm
–1.0 dBm
Not Available
68187C
0.01 – 2.0 GHz
2.0 – 20.0 GHz
20.0 – 40.0 GHz
40.0 – 50.0 GHz
50.0 – 60.0 GHz
+11.0 dBm
+10.0 dBm
+2.5 dBm
+2.0 dBm
+2.0 dBm
+10.0 dBm
+8.5 dBm
0.0 dBm
–1.5 dBm
–2.0 dBm
Not Available
68197C
0.01 – 2.0 GHz
2.0 – 20.0 GHz
20.0 – 40.0 GHz
40.0 – 50.0 GHz
50.0 — 65.0 GHz
+11.0 dBm
+10.0 dBm
+2.5 dBm
0.0 dBm
–2.0 dBm
Not Available Not Available
With Option 15A (High Power) Installed
68117C
0.01 – 2.0 GHz
2.0 – 8.4 GHz
+13.0 dBm
+17.0 dBm
+11.0 dBm
+15.0 dBm
+11.0 dBm
+11.0 dBm
68137C 2.0 – 20.0 GHz +17.0 dBm +15.0 dBm +7.0 dBm
68147C
0.01 – 2.0 GHz
2.0 – 20.0 GHz
+13.0 dBm
+17.0 dBm
+11.0 dBm
+15.0 dBm
+11.0 dBm
+7.0 dBm
68167C
0.01 – 20.0 GHz
20.0 – 40.0 GHz
+13.0 dBm
+6.0 dBm
+11.0 dBm
+3.0 dBm
Not Available
68177C 0.01 – 50.0 GHz Standard Standard Not Available
68187C 0.01 – 60.0 GHz Standard Standard Not Available
Table 1-1. Series 681XXC Models
GENERAL 681XXC
INFORMATION MODELS
Note: In models with Option 22 that have a high-end frequency of £20 GHz, rated output power is reduced by 1 dB
In models with Option 22 that have a high-end frequency of >20 GHz, rated output power is reduced by 2 dB.
